ICYRaid MB662U3-2S R1
Galería de imagenes
Carcasas HDD externas
(EOL)
Si usted es un profesional en la industria de los medios de comunicación entonces usted probablemente necesita un almacenamiento fiable de datos con funcionalidades que responden a sus proyectos más complejos. El ICYRaid MB662U3-2S R1 dispone de un inspector de RAID integrado, de una carcasa de aluminio robusta, de un ventilador silencioso con control de la velocidad y del diseño que permite retirar de su modo sus discos duros; esto lo hace la solución ideal para las aplicaciones de almacenamiento intensivo tales como la fotografía numérica, las bibliotecas de música, las salvaguardias de datos de alta velocidad, la edición audio y vídeo.

El MB662U3-2S R1 dispone del USB 3.0 con apoyo del USB Attached SCSI Protocol (UASP) para aumentar la velocidad en el momento de la transferencia o en el momento de la devolución de los ficheros voluminosos. El ICYRaid le permite escoger entre el RAID 0 (Rápido), el RAID 1 (Seguro), BIG y el modo JBOD para ver dos discos por separado. La versión MB662U3-2S R1 añade un indicador LED de reconstrucción para advertirle cuando un disco es defectuoso en modo RAID 1. Usted también puede cargar el software de vigilancia RAID a partir de nuestro sitio si usted prefiere ver informaciones detalladas sobre vuestros discos.
Una carcasa por disco duro hecho por profesionales para profesiones

El ICYRaid MB662U3-2S R1 es una bahía doble RAID para HDD que funciona independientemente de su ordenador. Lo que significa que no compartirá recursos sistema al contrario de un software RAID y usted puede conectarla a todo sistema que dispone de un puerto USB para acceder a sus datos inmediatamente sin cambiar sus configuraciones de almacenamiento. El MB662U3-2S R1 le da la posibilidad de escoger entre el RAID 0 (Rápido - Realización), el RAID 1 (Seguridad - Protección), el modo BIG y el modo JBOD.
RAID 0 (Rapido - Realización) usted puede fusionar dos discos en un único para un almacenamiento más importante y doblar la velocidad secuencial de lectura y de escritura hasta 300 Mb / seco en modo(moda) UASP. Esto es extremadamente útil para las transferencias de datos importantes o la lectura de varios flujos video HD.

RAID 1 (Seguridad - Protección) es la configuración ideal para los profesionales que no pueden permitirse perder su trabajo ensañado en el curso de una avería de disco tales como ingenieros o fotógrafos. No se preocupe más de perder todos sus datos si uno de sus discos duros tiene una avería. Basta con retirar el disco duro defectuoso y con insertar un disco de sustitución y con mirar su "reconstrucción" vía el indicador LED detrás.

Observación: en modo RAID 1, aunque la carcasa es defectuosa, sus datos son siempre accesibles con otras carcasas de disco duro, o directamente conectadas vía una conexión SATA sobre su PC de oficina (escritorio).

BIG- le permite combinar dos discos de capacidades diferentes en un volumen unicamente grande con el fin de maximizar su capacidad de almacenamiento

JBOD - Usted puede salvaguardar su datos en diferentes discos y leerlos independientemente. Esto es un modo excelente de clasificar sus datos en discos separados lo que es tan muy benéfico para todo nadie que desea atribuir diferentes discos para diferentes proyectos. Pueden cambiar muy simplemente los discos según el proyecto en el cual trabajan
Una concepción fácil
La instalación y el mantenimiento del MB662U3-2S R1 no necesitan ninguna herramienta suplementaria, porque todo lo que usted necesitará es incluye. El ICYRaid MB662U3-2S R1 utiliza nuestro diseño sin bandeja que se revela práctico en el caso de una transición con suavidad para comenzar una configuración. En cuanto sus discos duros están listos, basta con abrir cada puerta, con recoger sus discos duros y de seleccione el arreglo RAID que usted desea. Después de eso, la postura bajo tensión del aparato lanzará automáticamente el proceso.
El indicador LED a la delantera fácil a leer indica cuando un disco es eyectado, en curso de acceso o correctamente no es leído. Cuando el aparato es en el proceso de reconstrucción de la mesa RAID en modo RAID 1, un indicador luminoso de reconstrucción detrás lo fija. EL ICYRaid MB662U3-2S R1 añade un encargo LED de modo que el LEDs a la delantera como detrás puedan ser desactivados en caso de necesidad. Esto es ideal para la gente que puso el recinto en su cuarto y que prefiere apagar los videntes por la noche; esta función puede ser modificada vía el conmutador DIP sobre el tablero trasero. Además, el software fácil de usar de control RAID le permite vigilar fácilmente el estado del RAID y las informaciones SMART tanto sobre PC como Mac.
Performances extremamente rapidez
Saque provecho de la interfaz USB 3.0 con apoyo del UASP (los usuarios de PC necesitan Windows 8 y el apoyo del huésped, los sistemas Mac se encargan de él de base). Los usuarios se hallarán en situación de trasladar fotos, vídeos, películas y la música a velocidades fulgurantes. La interfaz USB 3.0 es también retro-compatible con USB 2.0, así, utilizar el MB662U3-2S R1 sobre su PC o Mac no presenta ningún problema. Si el sistema se encarga del USB 3.0, usted se halla en situación de sacar provecho de capacidades superiores - lo que es crucial para los profesionales que quieren herramientas que efectúan su trabajo rápidamente y eficazmente.
Calidad de construcción superior para una fiabilidad máxima
Es reconocido que las causas más corrientes de desfallecimiento de un disco duro son una mala gestión del calor y la agitación mecánica. Tomando esto en consideración, la construcción del MB662U3-2S R1 utiliza uno un cuerpo de aluminio macizo que añade: disipación del calor, de la fuerza y la protección de sus discos duros. El ICYRaid MB662U3-2S R1 le proporciona más en la reducción de las vibraciones externas encerrando el disco en una jaula que reduce las vibraciones, lo que minimiza los riesgos de daños del disco.
Un enfriamiento eficaz
Proteger sus datos también exige que sus discos o constantemente mantenidos para funcionar lo mejor posible. Porque los discos duros son sensibles al calor, es importante tener una solución activa de enfriamiento. Utilizar el ventilador de 40mm a rodamiento de bolas ultra silencioso a velocidad variable asegura una disipación óptima del calor o un funcionamiento silencioso para una gama de aplicaciones tales como un estudio de grabación o una sala de producción
EZConvert opcional por los suportes SSD 2.5”
Utiliza nuestra gama de convertidores de SSD EZConvert 2,5" hasta 3,5" para instalar un SSD 2,5" y aprovechar de su SSD una velocidad extremamente rapida mezclada a la velocidad del RAID 0 para una última experiencia de montaje video - Alcanza tasas de transferencia hasta 300 MB/s con este configuración. sequential transfer speed.
Características

*
Controlador RAID integrado que permite cuatro configuraciones diferentes: RAID 0 (Rápido), RAID 1 (Seguro), JBOD, y BIG.
*
Diseño sin herramienta para facilitar la actualización del disco duro o la sustitución.
*
Interfaz Plug y Play con USB 3.0 SuperSpeed y UASP.
*
Se encarga de 2 discos duros 3.5" tipos de SATA I / II II/III.
*
Se encarga de los últimos discos duros de 8 tipos de To por bahía en todos los modos RAID 4 para hasta 16 tipos de To de almacenamiento
*
Viendo a LED a la delantera para vigilar el estado de los discos en RAID.
*
Viendo a LED detrás para el estatuto RAID en reconstrucción.
*
Concebido por los usuarios profesionales en toda industria.
*
The front & rear LED can be disabled when needed.
*
Solid aluminum body construction for portability, heat dissipation and extra protection.
*
El LED antes y trasero pueden ser desactivados tan necesarios.
*
Cuerpo robusto de aluminio para la portabilidad, la disipación térmica y una protección suplementaria.
*
Construido con hendidura de seguridad para kit de cable de seguridad.
*
Compatible con Mac OS X Time Machine.
Video

Garandido 3 años
Número del modelo
MB662U3-2S R1
Color
Blanco con cuerpo en aluminio
Discos compatibles
2 HDD 3.5”SATA I, II y III
Interfaz
USB 3.0 (Retro-compatible con el USB 2.0)
Hasta 5Gb/sec via USB 3.0
Tasa de transferencia
Hasta 5Gb/sec via USB 3.0
Hasta 480Mb/sec via USB 2.0
Alimentación
Adaptador DC 12V/4A
Modos RAID
RAID 1 (seguro), RAID 0 (rápido), BIG y JBOD (no RAID)
Reglaje RAID
Interruptor horizontal
Enfriamiento
Ventilador de 40mm con control de la velocidad y del cuerpo en aluminio para una mejore dispersión del calor
Indicador LED por HDD
Bahía vacía - LED apagada
HDD en marcha - LED blanca fija
Problemas en relación HDD - LED rojo fijo
Reconstrucción RAID acabada - LED apagado
Interruptor por indicador LED
On y off
OS necesario
Win XP, Win 7, Win 8, Linux, Mac OS 10.2.8+
Estructura
Cuerpo en aluminio y plástico
Dimensión (L x W x H) :
8.07 x 5.28 x 2.4 in
Peso
830 g
Contenido del cartón
Aparato, manual, cable USB 3.0, Adaptador de alimentación, cable de alimentación
Documentos




ICY Conceptos

Add Drive Failure Protection to your NAS or Home Server System and Increase your Storage Capacity with the MB662U3-2S R1

The average home is becoming a digital playground for all types of media; therefore more and more home owners have begun adding Network Attached Storage to their home setup. With Network Attached Storage (NAS) or a home server you can easily share your documents, photos, videos and all types of media with multiple systems, including game consoles, smart TVs, desktop computers, MacBooks, media boxes, mobile devices and more. But what happens if the drive has failed? No worry, the ICY DOCK’s ICYRaid MB662U3-2S R1 is your answer. The ICYRaid MB662U3-2S R1 has a built-in RAID controller that operates independently of your computer. It takes 2 x 3.5” SATA HDD and supports the newest 8TB drives on the market which gives you up to 16TB total capacity in BIG / RAID 0 (FAST) mode, and up to 8TB total capacity in RAID 1 (SAFE) mode. The setup is easy, just simply connect the ICYRaid to your Home Server or NAS system with the USB interface and then you are able to exchange data between your server and ICYRaid.

The JBOD mode allows you to see two individual drives. With a unique tray-less design, you can use the ICYRaid as docking station for quick drive access; allowing you to swap your digital collection as easy as 1, 2, 3. You can also attach the MB662U3-2S R1 to your wireless router that has a USB 2.0 / 3.0 port and supports data share function.

Note: Your NAS, Wireless Router and Home Server need to support USB 2.0 / 3.0 with port-multiplier in order to see two drives in JBOD mode. We highly recommend you verify the specifications with your router manufacturer before you make your purchase.



Publicado el 15 de enero de 2016

Escrito por Tyler Bernath


"Performance, as seen in our testing, was quite good, not top notch USB 3.0 performance but solid nonetheless. In RAID 0, I was able to reach 397 MB/s read and 394 MB/s write and switching over to RAID 1 performance was nearly the same at 384 read and 392 write, which is plenty for hard drives."

Read more: http://www.tweaktown.com


Publicado el 13 de enero de 2016

Escrito por Roberto Jorge Tech Reviews


"The Icy Raid is a External Raid Enclosure Solution from Icy Dock, capable of Raid 0, Raid 1, JBOD and Big modes trough hardware Raid and with a USB 3.0 connection.

The built quality is great as its made of a brushed aluminum enclosure all around. The only plastic found is on the front bay doors as the back is also made of white metal."



https://youtu.be/LFFjv1foZTo


Publicado el 15 de abril de 2015

Escrito por Allyn Malventano


"I was impressed with the build quality of these two drive enclosures. They are reasonably durable and should have no issue safely containing drives. Their solid anodized aluminum shells are not bad to look at, either. The ICYRaid has simple hardware RAID features easily selected by a rear panel switch, making configuration a no brainer. The ICYCube only operates as a JBOD unit, meaning those desiring RAID are going to have to rely on software-RAID features of their OS (as well as the corresponding performance hit when using a software RAID through a single external interface link)."

http://www.pcper.com/

Publicado el 31 de marzo de 2015

Escrito por PureSolidness


"The ICYRaid is a self contained hardware dual bay RAID enclosure that operates independent of your computer. Along with an easy to use control panel, setting up the device is a simple thing to do."



https://youtu.be/kO8z1j0zjDE

Publicado el 1 de mayo de 2013

Escrito por Matt Humphreys


"I really like the Icy Dock in so many ways; the design has been thought out and everything just works. The Icy Dock is aimed at users who want fast external storage, combined into a unit that is sleek, subtle and well designed and on all counts the Icy Dock delivers. It is compatible with both PC and Mac and even comes with a 3 year warranty for peace of mind."

http://www.play3r.net
Publicado el 23 de abril de 2013

Escrito por Josh Shaman


"The Icy Dock offers a lot of value with its aluminum metal enclosure and cooling fan to prevent installed drives from overheating. The aforementioned appearance is good at the price point, though it could be improved with some more premium parts for the front bay doors and the rear panel. The switches are a bit tough to get to, but that's really for the drives' safety and shouldn't be held against Icy Dock. What really stands out though is that by providing users with the ability to configure their drives in RAID modes, performance gains are can be had without shelling out a lot of cash. In RAID 1, users should expect near identical performance to what a single drive would provide, and the HGST drives we installed proved that point. On the other hand, RAID 0 should offer double the performance. In our testing, the drives didn't quite achieve that 2x mark, however they were over 1.5 times quicker. Interfacing over USB 3.0 likely created a bottleneck limiting full enhancement. Overall, the gains in RAID 0 are solid, and the security offered by RAID 1 offers users an inexpensive backup option"

http://www.storagereview.com

Escrito por Ron Perillo -crowTrobot-

Publicado el 15 de abril de 2013


"The Icy Dock ICYRaid MB662U3-2S, unlike other external USB 3.0 enclosures has the hardware capability to run drives in RAID, independent of the PC. The ICYRaid MB662U3-2S replaces the discontinued MB662UEAB-2S which used the older USB 2.0 and FireWire connection with a much faster and more widely used USB 3.0 port. Users can install a pair of two 3.5” HDDs up to 4TB in capacity each for a total of up to 8GB of storage inside the Icy Dock MB662U3-2S. To cool both drives when they are continuously used, the ICYRaid MB662U3-2S is equipped with a 40mm Sunon MAGLev fan that operates silently and can be adjust through a built-in fan controller. Users can configure drives installed inside the MB662U3-2S in RAID 0, RAID 1, BIG, or JBOD just by simply moving the RAID toggle switch and pressing the reset button while the enclosure is on. No further steps are required, other than formatting the drives or adjust the partition when necessary of course. The Icy Dock ICYRAid MB662U3-2S is compatible with either Mac or PC and comes with a three-year limited warranty."

http://www.hitechlegion.com
Escrito por Tyler Bernath

Publicado el 14 de abril de 2013


"If you happen to find yourself in the market for external storage and want something elegant without sacrificing performance, the ICYRAID MB662U3-2S may be just what you're looking for."

http://www.tweaktown.com
Escrito por Stuart Davidson

Publicado el 30 de marzo de 2013


"With the bays open installation of a hard drive is simple. Just slide it in and close the door... perfect and the fact that even the latest SATA3 4TB models are supported is great.

Keeping things super easy ICY DOCK have done well to keep the device configuration to a hardware level. Rather than have to mess about in a BIOS, or application, we simply turn to the back of the unit and move the switches to the mode we want. The ability to enable/disable power LEDs and power saving is a nice bonus and we like that the fan speed can be varied.

We see the benefits of USB 3.0. Even with a single drive the ICYRaid easily exceeds the 35MB/s limit of most USB 2.0 ports by some way. When we combine drives in RAID0 for maximum performance the figures scale nicely and there are few external enclosures which can compete with this speed, flexibility and build quality."

http://www.hardwareheaven.com




Diciembre de 2015

Construya su propio pequeño servidor del factor de forma, teatro casero, y ordenador móvil con Intel NUC y recintos externos HDD/SSD
Febrero de 2015

Cómo ampliar su almacenamiento de la NAS con el USB 3,0 o recintos o unidades de disco duro externos del eSATA HDD
Octubre de 2014

Prevenga las fotos y el escape personales de los vídeos con la solución de almacenamiento
Junio de 2014

Cómo proteger sus datos previniendo Cryptolocker, Cryptodefense, y otro ataques de las mercancías del rescate con las copias de seguridad off-line
Marzo de 2014

Cómo asequible maximizar la eficacia del tiempo para los medios profesionales con el interfaz del USB 3.0
Septiembre de 2013

Guía de la selección del recinto de disco duro del para los profesionales de la empresa y de los medios
Enero de 2013

Cómo tener acceso fácilmente a datos sobre el mac y los ordenadores de la PC usando el FireWire800, el eSATA y recintos del disco duro del USB
Septiembre de 2012

Cómo seleccionar una solución del almacenamiento del USB 3,0 para su nuevo Macbook
Julio de 2011

Cómo a la copia de seguridad sus fotos, vídeo y datos en un dispositivo de almacenamiento seguro y seguro del RAID
Frequent Asked Questions


Q: What is RAID and what are different mode?

Note: Not all ICY DOCK enclosure support each of the RAID modes described below. For more information on the RAID modes that your enclosure supports, refer to the manual or the icydock.com product page.

Redundant Array of Independent Disks (RAID) is a virtual disk technology that combines multiple physical drives into one unit. RAID can create redundancy, improve performance, or do both.

RAID should not be considered a replacement for backing up your data. If critical data is going onto a RAID array, it should be backed up to another physical drive or logical set of drives.



The following are terms that normally used in connection with RAID:

• Striping: data is split between multiple disks.
• Mirroring: data is mirrored between multiple disks.
• Parity: also referred to as a checksum. Parity is a calculated value used to mathematically rebuild data.

Different RAID levels exist for different application requirements.


Refer to the following table for the list of RAID modes offered by some ICY DOCK products:
RAID MODE Description Operation Advantages Disadvantages Recovery
RAID 0 Striped disks Data is split evenly between two or more disks. Large size and the fastest speed. No redundancy. If one or more drives fails, this results in array failure.
RAID 1 Mirrored disks Two drives have identical data on them. A single drive failure will not result in data loss. Speed and size is limited by the slowest and smallest disk. Only one drive is needed for recovery.
JBOD Just a Bunch Of Disks Any number of drives are accessed independently by the operating system. Software RAID modes can be used. Hardware RAID may have better performance. N/A
BIG Spanning or Concatenation Data is written on one drive until it is full, and then the next drive(s) until it or they are full. Creates a very large and simple array. No redundancy. N/A


Q: How do I setup or change the RAID mode for my MB662U3-2S R1 USB 3.0 RAID Enclosure?

Note: Any data currently on the drives will be lost during this process. You need to back up all of your data before you set a RAID mode.



To set a RAID mode, complete the following:

1. Turn off the enclosure.
2. Use a USB 3.0 cable to connect the MB662U3-2S R1 enclosure to a computer.
3. Set the RAID switch to the RAID mode that you want to set.
4. Turn on the enclosure.
5. When the computer is turned on, check disk management to see if your RAID array is listed. If the RAID array listed with unallocated space, the RAID array needs to be reformatted.


Note 1: When you change the RAID mode, complete the steps above to set the unit back to JBOD before you set a different RAID mode.

Note 2: You can use the RAID monitoring software to verify the RAID model status. The RAID monitoring software can be downloaded here.



Q: How do I rebuild my RAID 1 array?

1. Determine which drive is operational by using the RAID monitoring software (if available) or test each drive individually on a different hard drive enclosure or by connecting each drive directly to a computer’s SATA port.
2. Replace the failed drive with an identical hard drive.
3. The array will rebuild and is accessible during the rebuilding process at a slow speed.


Note 1: It is recommended to use a new identical hard drive for the rebuild. To use a used drive, we recommend use Window’s DiskPart command to clean and format the used hard drive before you start rebuilding.

Note 2: Before you start the rebuilding process, make sure the replacement drive has no previous RAID table in it. To erase the RAID table created by MB662U3-2S R1, turn off the enclosure, insert the drive into the MB662U3-2S R1 and set the RAID switch to JBOD mode and then turn on the enclosure. The RAID table will be erased once you successfully switch to JBOD mode. This procedure deletes all of the data on the drives. Make sure you back up all your data before you switch to JBOD mode.

Note 3: For better data security, when creating RAID 1 array, the JMS562 RAID chipset saves the RAID table to a deep layer (LBA) of the drive, which can only be erased by JMS562 chipset (MB662U3-2S R1) in JBOD mode. Therefore, we recommend wiping the RAID table before you reuse any drive that ever used in MB662U3-2S R1 with RAID 1 array.



Q: How can I check if my USB device is properly detected by Mac OS?

To confirm that the Mac OS detects your USB device, complete the following:

Verify that the device appears in System Information: Choose Apple menu > About This Mac. In the window that appears, click Overview, then click the System Report button to open System Information. In the window that appears, see if the USB device is listed below Hardware in the list on the left.

You may need to refresh the System Information page after you plug in your device. To do so, press Command R with the System Information page open.

Your USB device is listed according to the name of the chipset. To determine the name of the chipset of your USB device, navigate to www.icydock.com and look on the Technical Specifications tab for your product.



Q: Will my hard drive or solid-state drive work in this enclosure?

• Make sure that the enclosure supports the storage size of your hard drive. If the storage size of your hard drive is larger than what the enclosure was tested with, the hard drive will likely still work with the enclosure.
• Confirm that your hard drive uses the same interface type as the enclosure. For example, IDE, SATA, or SAS.
• Make sure that the enclosure supports the physical size of your hard drive, such as 2.5 inches drive or 3.5 inches drive.
• Make sure that the enclosure supports the height of your hard drive. For example, 7mm, 9 mm or 15 mm.
• Verify that the power consumption of your hard drive doesn’t exceed the power output of the enclosure. If you’re using multiple hard drives, make sure that the combined power consumption of all of the hard drives doesn’t exceed the power output of the enclosure.


Q: Everything is connected, but nothing is working. What do I do?

When you troubleshoot issues with a hard drive enclosure, there are some quick tests that you can complete to rule out potential problems. You can test to make sure that the following components are working correctly and are not the source of the issue:
• Cables (USB, SATA, SAS, Mini-SAS, etc)
• Hard drives / SSD (M.2 drive, 3.5'' hard drive, solid state drive, etc)
• Hard drive enclosure (converter, mobile rack, cage, and external enclosure)

To test your setup components, try the following:
• Connect the hard drive directly to the system or use the hard drive in another enclosure to see if the problem is with the hard drive.
• Use the cables, hard drives, and hard drive enclosure in another setup to see if the problem is with the components or the setup.
• Use a different cable, hard drive, and hard drive enclosure in your setup to see if the problem persists. Ideally, you should test a component that you know works in another setup.

When you test the hard drive and hard drive enclosure, it is recommended that you do the following:
• To check Disk Management, press the Windows key + R, type diskmgmt.msc, and press Enter. Check to see if your hard drive is listed.
• If the hard drive is listed with unallocated space, the hard drive needs to be reformatted. Right-click unallocated and click New Simple Volume. Follow the on-screen instructions to complete the reformatting.

Note: Formatting a hard drive erases all of the data on it. Make sure that you back up all of your data before you reformat the hard drive.
• If the hard drive is listed as healthy but does not have a drive letter, for example, C:, right-click healthy and click Change Drive Letter and Paths. Click Add, assign a drive letter, and click OK.

Note: A formatted hard drive will not show up in Computer or My Computer until it has a drive letter assigned to it.

For additional help with setting ICY DOCK RAID enclosure, please contact us by email, phone, or live chat.
