CP024
Image Gallery
CONCEPT PRODUCTS

Low Profile Design for SFF Systems


CP024 is an ideal storage solution for small form factor computer systems where the space is limited, such as home theater computers, ultra compact gaming computers and small home servers.

Fully Loaded Features in a Small Package!



With CP024, you can easily turn any external 5.25” drive bay into a tray-less 3.5” SATA HDD docking with an extra space for a 12.7mm slim optical disk drive.



Dock for Hot-Swap



CP024 is designed for applications where hot-swap drive is often required. For examples: performing daily data backup to 3.5” hard drives, editing large video files directly on 3.5” hard drives, cloning data from HDD to HDD or hot-swapping OS drives. Thanks the unique drive docking design, users can simply insert the drives into the CP024 and start their tasks without the use of screws or trays to mount or dismount the drives. This effortless drive hot-swap capability makes CP024 a perfect tool for anyone who swaps their drives on a daily basis.



Same Space More Storage



We have implemented our high density storage technology in the CP024 and devised a way to store both 3.5” HDD and Slim ODD in a tight external 5.25” drive bay. The CP024 supports any 12.7mm height slim ODD which allows playback of a blu-ray HD movies or burning a huge data file into DVDs. With CPO024, both hard disk drive and optical disk drive can be installed just in a 5.25” bay, making it a perfect storage saver and an ideal solution for any small form factor system.


Key Features

*
Uses a single external 5.25” bay
*
Fits 1x 3.5” SATA hard drive
*
Fits 1x slim optical disk drive with 12.7mm height
*
Supports SATA 6Gb/s per drive slot
*
Front panel power button for easy access
*
Door-less design takes any 3.5” SATA hard disk drives without trays or holders
*
Large drive eject button for smooth drive removal action
* Flush in design for full drive protection from possible environmental damage
3 Years Warranty
Model Number :
CP024
Avaliable Color :
Black
Host Interface :
SATA III
Structure :
Metal
Drive Fit :
3.5" SATA III HDD (Full height & half height drive)
Device Fit :
1 x 5.25" front device bay
Maximum Transfer Rate
(Depending on drive speed) :
Up to 6Gb/s
Power Input :
1 x SATA 15pin
HDD Access Indicator ::
Power (Blue) ; HDD Access (Flashing Blue)
Hot-Swappable :
Yes (Except Slim ODD)
Dimension (L x W x H) :
8.27" x 5.83" x 1.63"
